NVIDIA GeForce RTX 5060 Ti 16GB is a mainstream Blackwell graphics card with a capacity-first 16GB memory configuration. This Product page records the official specification, launch pricing and the practical buying context used by 5000 Series. It is separate from our longer evidence-based Review, which assesses the card using cited independent testing rather than claiming hands-on testing.
Product overview
The 16GB version is the sensible RTX 5060 Ti. Its raw performance improvement is moderate, but the larger memory buffer avoids the severe capacity-related compromises that can affect the otherwise similar 8GB model.
The card launched with a US suggested price of $429 and a UK launch price of £399. Retail prices can move sharply with stock, partner coolers and factory overclocks, so the retailer links below are presented as non-affiliate price checks rather than as permanent price claims.
Core specifications
- 4,608 CUDA cores across 36 streaming multiprocessors
- 16GB GDDR7 on a 128-bit memory interface
- 28Gbps memory speed and 448GB/s rated bandwidth
- 2.41GHz base clock and 2.57GHz reference boost clock
- 180W total graphics power; 600W recommended system power
- three DisplayPort 2.1b and one HDMI 2.1b display outputs
Gaming position
This is fundamentally a very capable 1080p card and a solid 1440p option. At higher resolutions the narrow interface and midrange GPU limit peak speed, but 16GB protects texture quality and frame consistency far better than the 8GB edition.
The memory capacity is the defining advantage. Capacity does not make the GPU itself faster when a game fits comfortably inside 8GB, but it prevents abrupt texture, stutter and performance penalties when a demanding workload does not.
Ray tracing, DLSS and creator features
As a Blackwell graphics card, NVIDIA GeForce RTX 5060 Ti 16GB supports hardware ray tracing, NVIDIA Reflex and DLSS 4 features where a game implements them. Multi Frame Generation can lift displayed frame rates, but it does not replace strong native performance: image reconstruction, generated frames and latency should always be considered separately.
Its ninth-generation NVENC encoder and sixth-generation NVDEC decoder provide modern video support including AV1. That makes the card relevant not only to gaming but also to streaming, video export and creator applications whose acceleration paths support the installed GPU and driver.
Power, size and compatibility
The 180W board-power target is relatively easy to cool. Partner boards may use either a traditional 8-pin connector or a PCIe Gen 5 power connection, so verify the exact card rather than relying on a generic family image.
The reference interface is PCI Express Gen 5 x8. Display connectivity is three DisplayPort 2.1b and one HDMI 2.1b. Case clearance and slot thickness vary on partner models unless a Founders Edition dimension is stated, so check the exact manufacturer’s product page before ordering.
Who should consider it?
Choose it for a new midrange build, 1440p monitor or creator workload where 16GB is valuable and NVIDIA’s software ecosystem matters. It is usually worth the premium over the 8GB version when the total system is expected to last.
The main alternative is AMD’s Radeon RX 9060 XT 16GB, with RTX 5070 as the faster but more expensive NVIDIA step-up. Compare actual street prices, VRAM capacity, power supply requirements and the games or applications you use before treating one model as the automatic choice.
UK and US price checks
The retailer buttons on this page are plain, non-affiliate links. 5000 Series currently receives no commission from them. They are provided to make regional price checking easier while affiliate applications are pending; any future tracked link will be clearly labelled and will not influence the editorial verdict.
Review and sources
Read the full NVIDIA GeForce RTX 5060 Ti 16GB Review for the evidence-based assessment, performance context, pros, cons and verdict. Official specifications were checked against NVIDIA’s product information; the Review separately attributes the independent benchmark evidence it uses.
Specification notes
Published specifications describe reference behaviour. Add-in-board models may change boost targets, coolers, dimensions, connectors and warranty terms. Driver updates can also alter measured performance. We record launch MSRP for historical comparison and recommend confirming a live price immediately before purchase.
